| Pallet Racking - Frames | |||||
|---|---|---|---|---|---|
| Model Number | Frame Height | Frame Depth | Capacity (lbs.) | Weight (lbs.) | Price |
| DS-PRTD-10-42-19 | 120" | 42" | 19,380 | 53 | $197 |
| DS-PRTD-10-42-24 | 120" | 42" | 24,000 | 84 | $218 |
| DS-PRTD-12-42-19 | 144" | 42" | 19,380 | 66 | $224 |
| DS-PRTD-12-42-24 | 144" | 42" | 24,000 | 104 | $240 |
| DS-PRTD-14-42-19 | 168" | 42" | 19,380 | 76 | $264 |
| DS-PRTD-14-42-24 | 168" | 42" | 24,000 | 120 | $291 |
| DS-PRTD-16-42-19 | 192" | 42" | 19,380 | 83 | $287 |
| DS-PRTD-16-42-24 | 192" | 42" | 24,000 | 136 | $308 |
| All Dimensions are in inches | |||||
| Pallet Racking - Step Beams | |||||
|---|---|---|---|---|---|
| Model Number | Beam Height | Beam Length | Capacity (lbs. / pair) | Weight (lbs.) | Price |
| DS-BEAM-S-850 | 6" | 96" | 5,000 | 73 | $92 |
| DS-BEAM-S-870 | 6" | 96" | 7,000 | 77 | $106 |
| DS-BEAM-S-960 | 6" | 108" | 6,000 | 81 | $109 |
| DS-BEAM-S-970 | 6" | 108" | 7,000 | 91 | $124 |
| DS-BEAM-S-1050 | 6" | 120" | 5,000 | 85 | $121 |
| DS-BEAM-S-1070 | 6" | 120" | 7,000 | 104 | $157 |
| DS-BEAM-S-1250 | 6" | 144" | 5,000 | 145 | $163 |
| DS-BEAM-S-1260 | 6" | 144" | 6,000 | 165 | $204 |
| All Dimensions are in inches | |||||
| Pallet Racking - Wire Decking | |||||
|---|---|---|---|---|---|
| Model Number | Decking Depth | Decking Length | 2 Per Beam Length | Weight (lbs.) | Price |
| DS-WMD-4246 | 42" | 46" | 96" | 24 | $96 |
| DS-WMD-4252 | 42" | 52" | 108" | 25 | $109 |
| DS-WMD-4258 | 42" | 58" | 120" | 26 | $114 |
| All Dimensions are in inches | |||||
As seen in the photo below, Pallet Racking Wire Decking has three 13 gauge U channels with a uniform load capacity of 2,500 pounds.
| Pallet Racking - Crown Decking | |||||
|---|---|---|---|---|---|
| Model Number | Decking Depth | Decking Length | 2 Per Beam Length | Weight (lbs.) | Price |
| DS-SWMD-4246 | 42" | 46" | 96" | 24 | $96 |
| DS-SWMD-4252 | 42" | 52" | 108" | 25 | $109 |
| DS-SWMD-4258 | 42" | 58" | 120" | 26 | $114 |
| All Dimensions are in inches | |||||
As seen in the photo below, Pallet Racking Crown Decking has 6 gauge wire mesh with a uniform load capacity of 650 pounds. These sloping decks often helps the user do their job and have a powder coat finish.
| Pallet Racking - Open Area Decking | |||||
|---|---|---|---|---|---|
| Model Number | Frame Depth | Beam Length | Includes | Weight (lbs.) | Price |
| DS-PCH-96 | 42" | 96" | (2) 30" & (1) 36" | 62 | $154 |
| DS-PCH-108 | 42" | 108" | (3) 36" | 72 | $169 |
| DS-PCH-120 | 42" | 120" | (4) 30" | 82 | $200 |
| All Dimensions are in inches | |||||
As seen in the photo below, Pallet Racking Open Area Decking is ideal for products that require uniform support. This 22 gauge steel decking has a galvanized finish.
| Pallet Racking - Pallet Support Bars | |||||
|---|---|---|---|---|---|
| Model Number | Width | Length | Height | Weight (lbs.) | Price |
| DS-PSB-42 | 3" | 38-1/2" | 1" | 5 | $21 |
| DS-SSB-42 | 3" | 38-1/2" | 1-1/2" | 5 | $25 |
| All Dimensions are in inches | |||||
As seen in the 2 photos below, Pallet Racking Pallet Support Bars are ideal for economical support of pallets between step beams. The DS-SSB-42 fits flush with the top of the Pallet Support Bars. The DS-PSB-42 is 1/2" shorter and is for use with 1/2" plywood or 1/2" particle board.
| Pallet Racking - Frame Spacers (separates back to back frames) | ||
|---|---|---|
| Model Number | Space Between Frames | Price |
| DS-FSR-6 | 6" | $15 |
| DS-FSR-12 | 12" | $17 |
| All dimensions are in inches | ||
